Operating Manual TD2136DD Solar Drive RC-Movement, Transmitter DCF77 / Mainflingen, near Frankfurt/Main
Product Features:
• Radio-controlled, automatic time setting and clock change for Daylight Savings.
• Analogue disc date for Day/Date, perpetual calendar
• Reception Control
• Solar movement with rechargeable battery. No changing of battery! Duration of battery when fully charged is 6 months (without light).
• Low battery status indicator: Second-hand will jump in 2-second step.
• Battery Type: ML1220
General Information of Solar Technology
To avoid damage of the battery, the watch should always be charged up to its minimum. Therefore, it is recommended to store the watch in a light place.
1. Initial Setup (important for correct setting of the radio-controlled watch)
Due to heavy shocks or magnetic fields the hand position may differ from the internally saved radio time. The initial setup serves to resynchronise the hands
with the internally saved radio time.
For the basic time setting, pull the crown to position 1 and set the date to the calendar’s previous day/date by rotating the crown.
• Rotate the crown towards right/left to set the day/date to the yesterday’s day/date.
• Then, pull the crown up to its position 2 and press the MODE button to set the seconds hand step by step exactly to 12.
• Now set the hour and minute hands exactly to 12:00 o‘clock (midnight position). To do this, first rotate the crown (on pos. 2) towards right until the Date
display jumps to the current day. This happens only after 12:00 o’clock position at night. The date disc will adjust automatically in next steps. As the
case may be, the watch’s hands need to be reset a little backwards: to do this, rotate the crown backwards, left. Now all 3 hands are exactly at 12:00
o‘clock and the day is correct. Then, press the crown back into the zero position (rotate again tightly screwed crowns). Now, press MODE and radio-
signal will be received. The hands will rotate forwards to the correct time and set the day disc.
The initial setting is now complete. This process will take up to 8 minutes.
2. Checking Radio Reception and day
The radio clock will attempt to receive the DCF77 radio-control signal every day between 2:00 and 3:00. However, interference with reception might occur
due to thunderstorms or electrical disturbance.
• Press MODE.
• 1
st
: the second hand will show the day of the week (as per below table)
• 2
nd
: after this, the hand will show, if radio reception was successful (10:00 position) or fail (08:00 position) (as per below table).
• After this, the second hand return to move in normal mode. This will take up to one minute.
3. Manual Radio Reception signal
A manual call for the transmitter is always possible, but might fail due to bad weather conditions or electronic devices in the vicinity.
• Press the SET Button once.
• the second hand rotates to 12:00 and receiving the radio signal. The process will take 3-8 minutes.
WARNING:
·To ensure lasting durability please take note of the following points:
·DO NOT operate the crown or buttons in water or when the watch is wet.
·Never attempt to open the case of your watch. Batteries should be replaced by a qualified technician
·Never try to remove or replace the watch’s special battery by yourself.
·Usage of the wrong type of battery can damage the watch.
·"Do not swallow the battery, chemical Burn Hazard"
·This product contains a coin / button cell battery. If the coin / button cell battery is swallowed, it can cause severe internal burns in just 2 hours and can lead
death.
·keep new and used batteries away from children
·If the battery compartment does not close securely, stop suing the product and keep it away from children. If you think batteries might have been swallowed or
placed inside any part of the body, seek immediate medical attention.
Instructions for environmental protection
Disposal of old devices. At the end of its life, this product should not be thrown into the normal household waste, but must be handed over at a collecting point
for recycling electric devices. The appropriate symbol on the product or the User Guide indicates this accordingly. As per the markings, the materials are
recyclable. By recycling the materials or by other forms of recycling old devices you will be making a significant contribution to the protection of our
environs. Please obtain More information about this from the responsible waste disposal facilities of your community administrative authorities.
· Dispose of used batteries in a proper way. Do not throw away the watch indiscriminately, but dispose of it environmentally correctly. Use appropriate collecting
points or special waste dumps for this purpose. Disposal of packaging material. Packaging materials are raw materials and, therefore, recyclable. for the
sake of environmental protection, please dispose of these Properly. Your community administrative authorities will gladly provide with more information.
Conformity declaration
We hereby declare that this wristwatch is in conformity with the basic requirements and other applicable regulation of the directive 2014/53/EU.
This product complies with the EMV directives of the EU
TD2136DD 07/23
Trend News Europe GmbH, Eichholzer Str. 3c, D-21436 Marschacht
