4
6. Specifications:
Operating temperature: 0°C to 40°C
Operating voltage: 230V 50Hz
Switch rating: 16A resistive,
8A inductive,
1 HP, 750W incandescent,
750W halogen,
750W fluorescent,
100W compact fluorescent.
Minimum depth
of wall box: 32mm
Switch type: 22A micro switch
Voltage free contact: Yes
Contact type: Normally open
Power ON light: Yes
Time period: 24 hours
Note:
Product not suitable for discharge lighting.
5. Permanent Override:
The main slider on the timer can be set to
permanent ON by sliding it to the left, aligning the
arrow head to the 1 symbol.
In the middle position, with the arrow head pointing
at the timer symbol, the timer is in automatic mode.
If the slider is moved to the right, and the arrow head
points at the 0 symbol, the timer is permanently OFF.
