Time Module VD57C - Exploded View: Sub-Assemblies

0125 248
Train wheel bridge (A)
0241 178
Fourth wheel and pinion
0701 904
Fifth wheel and pinion (A) 0231 904
Third wheel and pinion
4146 890
Step rotor (A)
0261 034
0221 157 Minute wheel and pinion
Center wheel and pinion
0281 904
Setting wheel
4002 904
Coil block (A)
4239 357
Rotor stator (A)
0391 368
Train wheel setting lever
0383 368
Setting lever
0384 470
Yoke
0282 890
Clutch wheel
0962 890
Intermediate wheel
for date corrector (A)
*All parts code are sub
j
ect to chan
g
e without notice.
48
55
51
52
47
49
50
4
SII Products
56
53
54
43
44
45
46
PARTS CATALOGUE
Version-03
V
D57C
42
*1
*1
