5
5.3 Reset Unit:
Important: The BS8300 recommends that this should be sited on a wall
such that for a toilet it can be reached from the W.C. and a wheelchair.
The recommended height is between 750 and 1200mm above the floor
and horizontally it must not be mounted closer than 350mm to any corner.
• Having located the site, install a flush or surface mount single gang
wall box (see wall box minimum depth requirements for details).
• Pass the extra low voltage two core cable from the Over-Door Light
through the wall box and connect to the terminals marked ‘IN’
(See section 7. Extra Low Voltage Wiring).
• Bring a further extra low voltage two core cable into the wall box
and connect to the terminals marked ‘OUT’.
• Fit the Reset Unit to the wall box and secure using the fixing
screws provided.
5.4 Pull Cord Unit:
Important: The BS8300 recommends that this should be sited on the ceiling
such that for a toilet it can be operated from the W.C. and an adjacent area.
The lower handle should be set 100mm above the floor (knot and trim off
excess cord) and the upper handle should be set between 800 and 1000mm
above the floor (knot the cord at the required height).
• Having located the site, install a flush or surface mount single gang
wall box (see wall box minimum depth requirements for details).
• Pass the extra low voltage two core cable from the Reset Unit through
the wall box and connect to the terminals on the Pull Cord Unit
(See section 7. Extra Low Voltage Wiring).
• Fit the Pull Cord Unit to the wall box and secure using the fixing
screws provided.
