Timeguard EASZKN User Manual

2
• Operating Temperature: +5°C to 40°C
• IP Rating: Intended for indoor use only
• CE Compliant
• Dimensions:
Control Unit:
H=85mm, W=145mm, D=33mm
Over-Door Unit:
H=85mm, W=85mm, D=32mm
Reset Unit:
H=85mm, W=85mm, D=29mm
Pull Cord Unit:
H=85mm, W=85mm, D=30mm
Wall box minimum depth requirements – All Components:
Component
Minimum Depth
Requirement
Single Zone Control Unit 26mm
Over-Door Light 16mm
Reset Unit 16mm
Pull Cord Unit 16mm
• Features inside moulded dry lining back boxes may cause interference
with the product, the diagram below illustrates where these may occur.
• In the event of interference, the problem feature should be carefully
trimmed with a blade or cutters. To ensure correct installation an
MK or Centaur deep dry line box should be used.
4. Contents
• 1x Single Zone Control Unit
• 1x Over-Door Light
• 1x Reset Unit
• 1x Pull Cord Unit
• 1x W.C. Sticker
• 1x Instruction Manual

Timeguard EASZKN Specifications

General

Brand	Timeguard
Model	EASZKN
Category	Security System
Language	English
