ZV700 – Lower Flap Closed
1. General
The ZV700 combines the function of a manual lightswitch with
automatic timed control of lighting on a weekly basis available at the
slide of a switch. There is a further option of starting an automatic lighting
period at dusk but ending it in the usual way with a timed “OFF”.
Photocell window
Rocker switch – used in
manual operation
Lower flap hinges
open – see page 2
Supply
ON LED
