Timewave ANC-4 - TECHNICAL INFORMATION; SPECIFICATIONS

Operating Frequency Range 500 kHz to 80 MHz
(usable down to 100 kHz)
Signal Loss, Main Ant. to Radio 6 dB
Rf Input Level, Main Antenna 3 Vrms maximum
Maximum Transmit Rf Power 250 W PEP or Average
Through Unit
Time to Switch to Bypass When 7 mSec, typical
Transmit Rf is Detected
Time to Return to Receive Mode Approx. 500 msec or 7 msec, typical
When Rf is Not Present intenally selectable, (hang time)
Typical Local Noise Types Power Line Noise, Computer Noise,
TV Noise, etc.
Noise Cancellation Typically 40 dB or greater
Front Panel POWER switch, POWER LED,
PHASE RANGE switch, NOISE
PHASE control, FREQ RANGE
switch, NOISE GAIN control.
Rear Panel Power Input, Noise Antenna Input,
Main Antenna Input, Radio Output
Input Power +11 VDC to +16 VDC @ 150 mA,
reverse polarity protected
Size 1.7"H x 6"W x 4.3"D
(4.3cm x 15.2cm x 10.9cm)
Weight 2 pounds (.91 kG)
Temperature Ranges Operating: -20
o
C to +55
o
C
Storage: -40
o
C to +85
o
C
Humidity Up to 95% @ +55
o
C
12
SECTION 6
TECHNICAL
INFORMATION
SPECIFICATIONS
