BALANCE
ENDSHAKE
ADJUSTING
SCREW
ENERGY
CELL
CONNECTOR
FIGURE
R
If
the
complete
movement
is
taken
apart,
the
correct
order
for
reassembly
is
(see
explored
view
Page
253
.
2)
:
1. Place
the
minute
wheel
as-
sembly
in
the
dial
rest
and
then
carefully
position
the
plate
assembly on
top
of
the
dial
rest
.
2.
Third
wheel assembly.*
3. Friction washer.
4.
Index
lever assembly.
5. Index
wheel
assembly
.
6. Seconds wheel.
7.
Stem
bracket
.
8. Stop lever.
9.
Contact
spring
assembly
.
10
.
Train
wheel bridge
assembly
.
11
. Secure with
shunt
bridge
screw.
''
The
third wheel
assembly
and
the
friction pinion
should
be
as-
sembled
to
the
plate
assembly
as
follows :
Place
friction pinion
(pinion side down)
on
a
flat
anvil.
Place
the
plate
assembly
over
the
friction pinion.
Snap
third
wheel
assembly
(with friction
spring
in
position)
onto
the
end
of
the
friction pinion
as
shown
on
Page
253.13.
To
reassemble
balance
wheel
as
-
sembly,
assemble
the
balance
bridge
assembly
to
the
movement
with
two (2)
balance
bridge
screws
Ueave
screws
loose).
Tilt
the
balance
wheel
assembly
and
carefully
insert
the
pivot
on
the
hairspring
side
into
the
"V
-conic"
bearing
and
then
the
other
pivot
into
the
other
"V
-conic"
bearing;
tighten
the
balance
endshake
ad-
justing screw
enough
to
hold
the
balance
wheel
assembly
in
place
-see
Figure
R.
Place
energy
cell
connector
in position.
253.15
