Timotion TC15P Series User Manual

(User Manual-Control box)
6/12
Model list:
Model Input Max. Output (Actuator)
TC15P-ZQ120C 100-240VAC,50/60Hz,4A 32Vdc,10A
TC15P-ZQ120 100-240VAC,50/60Hz,4A 32Vdc,10A
Degree of protection against electric shock: No applied part
Protection against ingress of water: IP20
Mode of operation: Intermittent operation
This control box is designed to be used on motorized furniture and its basic function is to control
the movement of up to 2 electro-mechanical actuators.
Models TC15P-ZQ120C and TC15P-ZQ120 are identical except that 5V output.
The use of the output line is not more than 2 m.
Maintain & Cleaning:
- The control box is a maintain-free device. Under normal conditions, maintain is not
necessary.
- For some applications that not all DC Output (Actuator) connectors are used, the rubber
inserts are needed to seal those connectors which are not used. If these connectors are not
well sealed, the water/steam used in washing and cleaning may flow into the control box
which will cause unexpected damage to the control box.
