ThermocoupleLogger
Further Information
Further InformationFurther Information
Further Information
Further information on Tinytag data loggers, software and accessories can be
found on our web site at:
www.tinytag.info
www.tinytag.infowww.tinytag.info
www.tinytag.info
If you should have any further questions, please contact your distributor or:
Gemini Technical Support
Gemini Technical SupportGemini Technical Support
Gemini Technical Support
t: +44 (0)1243 813009 e: help@tinytag.info
Approvals
ApprovalsApprovals
Approvals
Gemini Data Loggers (UK) Ltd. operates a Business Management System which
conforms to ISO 9001 and ISO 14001.
Battery Information
Battery InformationBattery Information
Battery Information
The battery fitted in this product is a single cell containing less that 1g of lithium
and meets the requirements of the UN Manual of Tests and Criteria, Part III,
Subsection 38.3.
Recommended Battery Types
Recommended Battery TypesRecommended Battery Types
Recommended Battery Types SAFT LS14250,
Tekcell SBAA02P or
Eve ER14250
The logger will operate with other ½AA 3.6V Lithium batteries but performance
cannot be guaranteed.
Replacement Interval
Replacement Interval Replacement Interval
Replacement Interval Annually
Before replacing the battery the data logger must be stopped.
Data stored on the logger will be retained after a battery is replaced.
9800-0116: Issue 4 (9th August 2019)
LED Flash Patterns
LED Flash PatternsLED Flash Patterns
LED Flash Patterns
When logging, status LEDs on the front of the logger will flash as follows:
Flash Pattern
Flash PatternFlash Pattern
Flash Pattern
Indication
IndicationIndication
Indication
A green flash every 4 seconds Logging
A green flash every 8 seconds Waiting to log (set for a delayed start)
A red flash every 4 seconds Alarm limit breached
For more information on the alarms and how they work, please see the Tinytag
Explorer quick start guide and help file.
Physical Specification
Physical SpecificationPhysical Specification
Physical Specification
Logger
LoggerLogger
Logger
IP Rating
IP RatingIP Rating
IP Rating IP51
Working Temperature Range
Working Temperature RangeWorking Temperature Range
Working Temperature Range
-40 to +85°C (-40 to +185°F)
Case Dimensions
Case DimensionsCase Dimensions
Case Dimensions
Height
HeightHeight
Height 42mm / 2.83”
Width
WidthWidth
Width
60mm / 2.36”
Depth
DepthDepth
Depth
33mm / 1.30”
Weight
WeightWeight
Weight 65g / 2.29oz
Supplied Type K Thermocouple
Supplied Type K ThermocoupleSupplied Type K Thermocouple
Supplied Type K Thermocouple
Temperature Range
Temperature RangeTemperature Range
Temperature Range
-100 to +250°C (-148 to 482°F)
Lead length
Lead length Lead length
Lead length 1m / 39.37”
Warranty
WarrantyWarranty
Warranty
This product carries a manufacturing defects warranty of 12 months from the date
of purchase. Units returned under warranty will be repaired or replaced at the
manufacturer’s discretion. This warranty does not cover mishandling, modification
or battery replacement and is subject to the standard Terms and Conditions of
Sale, a copy of which is available on request.
The equipment/goods are sold “as is” and with “all faults” (applies in USA).
The equipment/goods are sold “as is” and with “all faults” (applies in USA). The equipment/goods are sold “as is” and with “all faults” (applies in USA).
The equipment/goods are sold “as is” and with “all faults” (applies in USA).
Claims under warranty should be referred to the point of sale.
Claims under warranty should be referred to the point of sale.Claims under warranty should be referred to the point of sale.
Claims under warranty should be referred to the point of sale.
Disposal
DisposalDisposal
Disposal
Data loggers, accessories and batteries should be disposed of at
organised facilities, where available, in compliance with local
regulations.
In accordance with the WEEE directive Gemini Data Loggers (UK) Ltd.
will take back and dispose of any equipment purchased directly.
Equipment not purchased directly should be returned to the point of
sale for disposal.
Notes
NotesNotes
Notes
If used at low temperatures the data logger should be allowed to warm to room
temperature before it is opened to avoid condensation forming inside it.
The IP51 rating is valid only when the logger’s connector cover is fitted and the
unit is orientated with it’s hanging tab uppermost.
Trigger Start
Trigger Start Trigger Start
Trigger Start
The trigger start option allows a logger to be set up as required and then started
at a later time with a magnet. The position of the trigger start switch is indicated
by the • • • marking on the back of the logger. When the "Wait until trigger
event" option is selected in the Tinytag Explorer software the green LED on the
logger will flash once every eight seconds to indicate that it is waiting to start.
When a magnet is swiped past the • • • marking, the green LED will light to
indicate the switch is closed. After the magnet has been removed, the green LED
will flash every four seconds to indicate that the logger is recording.
Calibration
CalibrationCalibration
Calibration
This logger is configured to meet Gemini’s quoted specification during its
manufacture.
We recommend that the calibration of the logger should be checked annually
against a calibrated reference meter.
A certificate of calibration, traceable to national standards, can be supplied for an
additional charge either at the point of purchase, or if the logger is returned for a
service calibration.
