12
4. With available take-up tighten belts enough to keep from slipping during operation. Ideal belt tension is the
lowest tension at which the belt will not slip under peak load conditions. The drive side of the belt(s) should be
straight across and the slack side should show a slight bow.
5. Do not place new belt(s) on worn sheaves.
6. If multiple belts are used, replace all belts with a new set or matched belts.
7. Do not use belt dressing on belt(s) which are slipping. Belt dressing will damage the belt and cause early
failure. Tighten belt(s) to proper tension, or if dirty, clean the belt(s) with a commercial rubber solvent.
CHECK V-BELTS AND SHEAVES ONLY WHEN CONVEYOR IS STOPPED!
CHAIN & SPROCKETS
For longest chain life a constant lm or oil is recommended. We recommend a good quality non-detergent petroleum base
oil. Use the chart below
SHUT OFF CONVEYOR BEFORE USING OIL CAN OR BRUSH TO APPLY OIL!
REMEMBER - ALL GUARDS AND BOTTOM PANS, IF PROVIDED, MUST BE
REPLACED BEFORE RUNNING CONVEYOR. TITAN INDUSTRIES IS NOT
RESPONSIBLE FOR INJURIES CAUSED BY NOT COMPLYING WITH
SAFETY INSTRUCTIONS.
DANGER
!
DANGER
!
WARNING
!
TEMPERATURE
RECOMMENDED OIL
VISCOSITY
20 degrees - 40 degrees F SAE 20
40 degrees - 100 degrees F
SAE 30
100 degrees - 120 degrees F SAE 40
120 degrees - 140 degrees F SAE 50
Return to Table of Contents
