7
FIGURE 6
Model 111 Bottom Mount Drive
Model 111 Center Drive & Take-up
Model 110 Bottom Mount Drive
Model 110 Center Drive & Take-up
Model 110 & 111 Belt Threading
4. After making sure the conveyor is cleared off and the drive pulley is moving the belt in the correct direction, run
the conveyor. Take up slack belt with the take-up provided until there is no slippage between the drive pulley
and the belt.
A GENERAL RULE FOR CORRECT BELT TENSION IS THAT THE BELT MUST BE
TIGHT ENOUGH TO MOVE YOUR PRODUCT AT FULL LOAD. OVERTIGHTENING
OF THE BELT WILL CAUSE THE BELT, PULLEYS, BEARINGS, AND DRIVE
COMPONENTS TO WEAR OUT PREMATURELY.
III. MAINTENANCE
BELT TRACKING - to see the instructional video on YouTube
www.youtube.com/watch?v=4O5YSukH9as
1. The rst step in belt tracking is to make sure all pulleys are parallel with each other and perpendicular to the frame.
Once this has been done refer to FIGURE 7 for proper tracking adjustments on end drive conveyors or FIGURE 8
for proper tracking on center drive and take-up conveyors.
CAUTION
!
Return to Table of Contents
