3
SECTION 1
Introduction to STE-8000 sensors
Models STE-8001 and STE-8201 are wall-mounted, temperature sensor for use
with Titus BAC-8000 series VAV controllers. Key features include the following:
Integrated operator interface ready to use with BAC-8000 series VAV
controllers
Large LCD display
Simple three-button interface
Continuously displays temperature and time
Separate password protection for user and commissioning functions
Use as a service tool to set up BAC-8000 series VAV controllers
Optional motion sensor to detect space occupancy
Note
The STE-8000 series sensors will display time if the controller to which they are
attached have been synchronized with system time within the previous 24
hours.
Illustration 1-1 STE-8001 and STE-8201
STE-8001
STE-8201
This section provides a description of the Titus STE-8001 and STE-8201 wall
sensors. It also introdeces safety information. Review this material before
installing or operating the sensors.
