TJM Pro Series - Compressor Specifications; Electrical Specifications; Performance

TJM Pro Series Twin Compressor: Installation and User Manual
For product warranty please refer to our website www.tjm.com.au
File: F-31070
Page 3 of 23
23/02/2021
1. Compressor Specifications
Electrical Specifications
Voltage
12 V DC
Current Draw (0 Bar / 0 PSI)
46 A
Current Draw (30 PSI)
55 A
Fuse Type and Rating
2x ANS 40 A
IP Rating
54
Motor thermal cut-off
105°C
Performance
Air flow (0 Bar / 0 PSI)
170 LPM / 6.0 CFM
Air Flow (2 Bar / 29 PSI)
120 LPM / 4.2 CFM
Duty Cycle (80 PSI, 60 minutes @ 23°C)
100 %
Pressure Switch Operation
Off @ 120 PSI / On @ 90 PSI
Safety Relief Valve Opening Pressure
1070 kPa / 155 PSI
Hardware and Fittings
Pro Locker Solenoid / Pressure Switch ports
4 x ⅛” BSPT ports (2 each side of air tank)
Tyre Inflation / Accessory ports
5 x ¼” BSPT ports (2 each side of air tank & 1 on Top
Cover)
Safety Relief Valve
Factory-set 155 PSI, ⅛” NPT male thread
Compressor to Bracket Bolts (Included)
12 x M5 x 22 Socket Head Cap Screw (Base Bracket)
6 x M5 x 18 Socket Head Cap Screw (Top Cover)
Base Bracket to Mounting Surface Bolts
(Included)
6 x M8 x 1.25 x 30 Socket Button Head Cap Screws
6x M8 x 1.25 Hex Nyloc Nuts
12x M8 x 18 x 20 Flat Washers
Recommended Fastener Torque Settings
M5
5 Nm + / - 10%
M6
9 Nm + / - 10%
⅛” BSPT
5 - 6 Nm
¼” BSPT
6 - 8 Nm
