TJM Pro Series - Page 5

TJM Pro Series Twin Compressor: Installation and User Manual
For product warranty please refer to our website www.tjm.com.au
File: F-31070
Page 5 of 23
23/02/2021
Bill of Materials
Item No.
QTY
Part Number
Description
1
1
F-30747
TJM Pro Series Compressor Assembly
2
2
ANS FUSE ASSEMBLY
ANS Fuse Assembly
3
1
5-PIN CONNECTOR FEMALE
‘Delphi” Style 5 Pin Connector Plug - Female
4
1
F-14002
Wiring Harness – Cabin
5
1
F-30638
Solenoid & Pressure Switch Harness
6
1
013COMPVACTSWITCH
Compressor Activation Switch Kit
7
1
F-30798R
Vertical Brace – Right Hand Side
8
1
F-30798L
Vertical Brace – Left Hand Side
9
2
K3099
M10 x 1.25 ZG – Nut Hex Nyloc
10
2
K0567
M10 x 1.25 x 50 Hex Bolt – ZP DIN
11
12
M8 FLAT WASHER
Washer Flat M8 x 18 x 2.0 ZP
12
6
K0606
M8 x 1.25 ZP – Nut Hex Nyloc
13
2
F-30772
Bracket Backing Strip
14
1
F-31070
013COMVPROT Owner’s Manual
15
8
F-30893
5mm x 23 OD x 11 ID Spacer
16
4
WSST-W13
Washer Flat M10 x 34 x 3
17
6
K0533
M8 x 1.25 x 30 Socket Button Head Screw
18
1
F-31390
Base Bracket Drill Template
19
1
F-31397
Vertical Wall Brace Drill Template
