TLR 8IGHT-T E 3.0 - Rear Hub & CV Assembly; REAR TOE-IN ADJUSTMENT; REAR ANTI-SQUAT ADJUSTMENT

29
29
D-5
EN Rear Hub & CV Assembly
DE Zusammenbau Hinterachse und CV
FR Assemblage des fusées et cardans arrière
IT Assemblaggio mozzo posteriore & CV
LOSA3530
TLR-LOK
L
R
L
R
L
LOSA6296
LOSA3518
7
5
6
LOSA6945
LOSA1731
LOSA6953
4
LOSA3522
3
LOSA3518
2
1
LOSA3523
LOSA3586
D-6
EN Rear Suspension Arm Assembly
DE Zusammenbau des Heckquerlenkers
FR Installation des triangles arrière
IT Assemblaggio bracci sospensione posteriore
L
R
L
R
L
LOSA6296 x 1
F 8-32 x 1/8”
LOSA3518 x 1
2.5 x 12.80mm
LOSA3518 x 1
3 x 17mm
LOSA6945 x 1
8 x 14 x 4mm
LOSA6953 x 1
1/2” x 3/4”
REAR TOE-IN ADJUSTMENT
Insert Position Insert Number Total Toe-In
Inside 1 2°
Inside 0.5 2.5°
Middle 0 3°
Outside 0.5 3.5°
Outside 1 4°
REAR ANTI-SQUAT ADJUSTMENT
Insert Position Insert Number Total Anti-Squat
Up 1 4°
Up 0.5 3.5°
Middle 0 3°
Down 0.5 2.5°
Down 1 2°
SPUREINSTELLUNG HINTEN
Einsatz Position Einsatz Nr. Vorspur
Innen 1 2°
Innen 0.5 2.5°
Mitte 0 3°
Aussen 0.5 3.5°
Aussen 1 4°
ANTI SQUAT EINSTELLUNG HINTEN
Einsatz Position Einsatz Nr. Anti Squat
Oben 1 4°
Oben 0.5 3.5°
Mitte 0 3°
Unten 0.5 2.5°
Unten 1 2°
