TLV LA Series - User Manual

Questions and Answers

J
Jeffrey RodriguezJul 29, 2025
Why is steam leaking from the outlet of my TLV Fan?
- T
  Thomas BooneJul 29, 2025
  Steam leakage from the outlet of your TLV Fan can occur due to several reasons. Rust or scale may be present between the X-element valve and valve seat, in which case you should clean the parts. The X-element valve and valve seat may be damaged, requiring replacement with a new X-element and/or cover (LA13L: also the valve seat). A broken X-element also needs replacement. Improper installation or air vent vibration (which can be fixed by lengthening the inlet piping and fastening it securely) could also be the cause.
S
shelleynewmanAug 7, 2025
What to do if my TLV Fan is not discharging air properly?
- S
  Spencer WilkinsonAug 7, 2025
  If your TLV Fan isn't discharging air properly, several issues could be the cause. The X-element might be stuck to the valve seat, or the valve seat itself could be blocked; in either case, cleaning the parts or replacing the valve seat/cover (LA13L) is recommended. A clogged screen can also cause this issue, so cleaning the parts is advised. Also, make sure that the air vent operating pressure doesn't exceed the maximum specified pressure, and that there is sufficient pressure differential between the air vent inlet and outlet. Compare the specifications with the actual operating conditions.
S
Sarah TranAug 18, 2025
How to fix steam leaking from my TLV Fan (not the outlet)?
- S
  Samantha LewisAug 18, 2025
  If steam is leaking from somewhere other than the outlet on your TLV Fan, it's likely due to gasket deterioration or damage, in which case you should replace it with a new gasket. It could also be due to improper tightening torques, so ensure you tighten to the proper torque.

Summary

Introduction

Safety Considerations

Essential safety precautions, including DANGER, WARNING, and CAUTION levels.

2. Specifications

2.1 Maximum Operating Temperature

Chart detailing operating temperature limits versus pressure for LA Series.

3. Configuration

4. Exploded View

5. Proper Installation

6. Piping Arrangement

7. Operational Check

8. Inspection and Maintenance

9. Troubleshooting

10. TLV Express Limited Warranty

Summary

Introduction

Safety Considerations

Essential safety precautions, including DANGER, WARNING, and CAUTION levels.

2. Specifications

2.1 Maximum Operating Temperature

Chart detailing operating temperature limits versus pressure for LA Series.

3. Configuration

4. Exploded View

5. Proper Installation

6. Piping Arrangement

7. Operational Check

8. Inspection and Maintenance

9. Troubleshooting

10. TLV Express Limited Warranty

TLV LA Series Specifications

General

Bearing Type	Ball Bearing
Frequency	50/60 Hz
Operating Voltage	115 VAC or 230 VAC (depending on model)
Voltage	115 VAC or 230 VAC (depending on model)
Life Expectancy	50, 000 hours
