TMC 30E - Page 115

Injection Molding Machine Chapter 5
V3.0
5-10
Content of Alarm Cause of Alarm Release of Alarm
17. Safety door front be
open
Please check front
safety door & input
no. 101
M/S/A: I/O 101 OFF Close operation safety gate
18. Safety door rear be
open
Please check rear
safety door & input
no. 103
M/S/A: I/O 103 OFF Close rear safety gate
21. Thermocouple
abnormal
Please check
temperature
page(opn/inv)check
couple open/inverse
M/S/A: Thermocouple
disconnected.
1. Check heater band， wire，
fuse， SSR， thermocouple
24. Mold open time over
Please check clamp
setting
S/A: T/C 325 clamp open
monitor time over
1. Open safety gate
2. Adjust T/C 325 set value
3. Check clamp open/close
mechanism and hydraulic
circuit.
25. Core in/out position
abnormal
Please check core
position & setting
M：manual corepull
performed not in core-in
core-out position
S/A: during corepull
operation， T/C 321-full
cycle time over
M/S/A: eject operation
performed not in
corepull out ending
position.
1. Open safety gate
2. M: move clamp open/close
to corepull position， then
perform corepull.
3. S/A: adjust T/C 325 set
value
4. Check corepull device.
27. Lot parts count over
S/A: T/C 445-lot quantity
counting exceeded
1. Open safety gate
2. Upon completion of T/C
444 lot quantity， alarm
time will be cleared
automatically
