10 barg 2,2 kW 0,23 mc/min
145 psig 3 HP 8 cfm
Pressure Power Air Capacity
10 barg 3 kW 0,32 mc/min
145 psig 4 HP 11,5 cfm
Pressure Power Air Capacity
7 barg 3 kW 0,40 mc/min
100 psig 4 HP 14 cfm
Pressure Power Air Capacity
Drive: Male
Lobe combination: 5/6
Male rotor size: 71,6 mm
Female rotor size: 47,5 mm
L/D: 1,25
Working pressure: min 3 barg/40 psig – max 10 barg/145 psig
Weight: 60 Kg – 132 lbs
2
SCI6
P
Data Tables
Outside view drawing
7 barg 2,2 kW 0,30 mc/min
100 psig 3 HP 10,5 cfm
Pressure Power Air Capacity
