TMC SCI Series - SC18 BM Model Details; SC18 BM Outside View Drawing; SC18 BM Performance Data Tables

4
Data Tables
Outside view drawing
SCI8BM
Speed (rpm)
Air Capacity
Air Capacity (cfm)
Speed (rpm)
3000 4000 5000 6000 7000 8000
0,5
0,7
0,9
1,1
1,3
1,5
1,7
1,9
10 barg
Air Capacity
Air Capacity (mc/min)
3000 4000 5000 6000 7000 8000
10
20
30
40
50
60
70
145 psig
Drive: Male
Lobe combination: 5/6
Male rotor size: 74 mm
Female rotor size: 61,6 mm
L/D: 1,65
Working pressure: min 3 barg/40 psig – max 13 barg/190 psig
Weight: 52 Kg – 115 lbs
Power
Power (kW)
Speed (rpm)
Power
Power (HP)
Speed (rpm)
3000 4000 5000 6000 7000 8000
13 barg
10 barg
7 barg
4
6
8
10
12
14
16
18
3000 4000 5000 6000 7000 8000
5
7,5
10
12,5
15
17,5
20
22,5
25
190 psig
145 psig
100 psig
