CAM-BOLT and CAM-LOCK
INSTRUCTIONS
Align the arrow on the Cam-lock to the Cam-
bolt head and insert the Cam-lock.
CAM-LOCK
�
+
@®
; ;
CORRECT
WRONG
CAM-BOLT
I
nsert
C
am-bolt
into
the
pre
-
drilled
hole
. U
se
a
P
hillips
S
crewdriver
to
tighten
until
shoulder
is
flush with
the
panel
. S
ee
illustrations
below
.
SHOULDER
X
Use a flat screwdriver to turn the Cam-Lock
clockwise one half a turn so it locks onto the head
of the Cam-lock. Turn only until it is snug – over-
tightening could damage Cam-lock or/and Cam-bolt
3/10
