OPERATION
DISPLAY
LCD TNE 881 Intelligent speed regulating handle instructions
Special for TNE-SCOOTER
Version Number: 20150930
Item No: TNE 881 - A
WARNINGS
Release speed control before braking!
2.1 Working Voltage: DC24V 36V (Setting of the meter)
48V (According to customers’ requires to customized)
2.2 Mode of connection:
1. Red Line (D+): Enter of the power’s plus
2. Black Line (GND): Power’sminus
3. Blue Line (DS): Controllerelectricdoorlock
4. Yellow Line (SC): Brakesignal
5. Green Line (RX): Received the communication
6. White Line (TX): Sendthecommunication
Working Voltage and Mode of Connection
Any Questions Contact with TNE: info@tne-group.net
www.tne-scooter.com www.tne-group.net
To Next Page
