33
NOTE: * If regular driving is in arid or coastal condition, air filter and engine oil may need
replaced more frequently.
RECOMMENDED: To insure warranty and quality performance have a TN’G dealer
perform regular maintenance.
TIRE PRESSURE / TREAD
Measure the pressure of each tire. The correct pressures are: Front 29 PSI / Rear 33 PSI.
Visually inspect the tires for damage and wear or abnormal tread wear. Look for nails, glass,
stones or any sharp object cutting into the tire casing. The middle of the tread depth should
have: Front 1.5mm / Rear 2mm
CAUTION: This scooter uses tubeless tires on the front and rear wheels, always replaced
with tires of the same type.
REAR BRAKE ADJUSTMENT
Fig. 1 Fig. 2
Fig. 3
(Del Rey Only)
Total free play for brake lever should not exceed 30 mm. To firm up brake, turn nut clockwise
until you reach the acceptable level. Turn it counterclockwise to soften brake.
