Toa F-122CU2 User Manual

4
3. FEATURES
• Bass-reflex speaker system designed to provide a wide frequency range and high power handling capability.
• Wide-dispersion flush-mount ceiling speaker design employs unique acoustic construction to realize a wide
area of coverage. Uniform sound output levels are achievable not only directly under the speaker, but also
over a wide radius.
• Because the speaker is provided with both low- and high-impedance operating capability, it can be used in
many different applications. Front panel-mounted input selector switch permits easy verification and change
of current impedance settings.
• Easy installation. Can be quickly and accurately mounted to ceilings.
• Rotating front grille can be installed quickly and conveniently.
• Attractive exterior design specially created by an interior designer blends naturally with any architectural
space, enhancing the immediate area's sense of harmony.
4. NOMENCLATURE AND DIMENSIONS
[Ceiling mounting]
Tile bridge
(accessory)
Mounting hole: ø200 (7
7
/8)
Ceiling tile
Max. 202 (7
61
/64)
Max. 37 (1
29
/64)
Safety wire (accessory)
ø230 (9
1
/16)
40 (1
37
/64)
238 (9
3
/8)
ø195 (7
43
/64)
Approx. 600 (23
5
/8)
[Front] [Side]
[Rear]
Safety wire hook
Choke
bracketConnector cover
Front grille
(accessory)
Unit: mm (inches)
