8. SPECIFICATIONS
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
Front grille ............................................................ 1
Paper pattern ....................................................... 1
• Optional Component
HY-RR1 (Reinforcement Ring): Reinforcement fitting dedicated to the F-1522SC to be used when the ceiling
is weak
Rated Input 6 W (High Impedance)
Power Handling Capacity Continuous pink noise: 9 W (8 Ω), 6 W (16 Ω)
Continuous program: 18 W (8 Ω), 12 W (16 Ω)
Impedance 100 V line: 1.7 kΩ (6 W), 3.3 kΩ (3 W)
70 V line: 830 Ω (6 W), 1.7 kΩ (3 W), 3.3 kΩ (1.5 W)
25 V line: 830 Ω (0.75 W), 1.7 kΩ (0.4 W), 3.3 kΩ (0.2 W)
16 Ω, 8 Ω
Sound Pressure Level 88 dB (1 W, 1 m)
Frequency Response 65 – 18,000 Hz (–10 dB), 45 – 20,000 Hz (–20 dB)
at installation in 1/2 free sound field
(Measured by installing the unit in the center of a ceiling.)
Speaker Component 10 cm (4") cone-type
Mounting Hole ø135 mm (5
5
/16")
Maximum ceiling thickness: 37 mm (1
29
/64")
Input Terminal Push-in connector (Bridging terminal-2 branch type)
Usable Cable 600 V vinyl-insulated cable (IV wire or HIV wire)
Solid copper wire: ø0.8 – ø1.6 mm (equivalent to AWG 20 – 15)
Stranded copper wire: 0.75 – 1.25 mm
2
(equivalent to AWG 18 – 17)
Finish Baffle: Fire-resistant ABS resin (resin material grade: UL-94 V-0
or its equivalent), black
Rim: Fire-resistant ABS resin (resin material grade: UL-94 V-0
or its equivalent), white, paint
Punched net: Steel plate, white, paint
Dust cover: Artificial fiber, black
Dimensions ø155 (6
7
/64
") x Depth 117 mm (4
39
/64
")
Weight 1 kg (including front grille)
