Toa F-2322C User Manual

Printed in Indonesia
533-06-093-10
9. SPECIFICATIONS
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
Front grille ............................................................ 1
Ceiling reinforcement ring .................................... 1
Safety wire (approx. 60 cm or 23
5
/8") .................. 1
Paper pattern ....................................................... 1
• Optional Components
HY-TB1 (Tile Bar Bridge): Place this bridge on the ceiling frame when mounting the speaker unit to
a weak suspended ceiling.
HY-TR1 (Trim Ring): Use this ring when mounting the speaker in pre-existing holes that are
larger than the designated 200 mm (7
7
/8") in diameter.
HY-AH1 (Anchor Hanging Bracket): Attach this bracket to an anchor bolt when mounting the speaker unit to a
weak ceiling.
HY-BC1 (Back Can): Use this Back Can when mounting the speaker unit in exposed hanging
applications.
F-2322C F-2352C
Bass reflex type
30 W (High Impedance)
Continuous pink noise: 60 W (8 Ω), 30 W (16 Ω)
Continuous program: 120 W (8 Ω), 60 W (16 Ω)
100 V line: 330 Ω (30 W), 1 kΩ (10 W), 3.3 kΩ (3 W), 10 kΩ (1 W)
70 V line: 170 Ω (30 W), 330 Ω (15 W), 1 kΩ (5 W), 3.3 kΩ (1.5 W), 10 kΩ (0.5 W)
25 V line: 170 Ω (3.7 W), 330 Ω (1.9 W), 1 kΩ (0.6 W), 3.3 kΩ (0.2 W),
10 kΩ (0.06 W)
16 Ω, 8 Ω
90 dB (1 W, 1 m)
70 – 20,000 Hz (–10 dB), 50 – 20,000 Hz (–20 dB)
at installation in 1/2 free sound field
(Measured by installing the unit in the center of a ceiling.)
12 cm (5") cone-type High frequency: Balanced dome-type
Low frequency: 12 cm (5") cone-type
ø200 mm (7
7
/8")
Maximum ceiling thickness: 37 mm (1
29
/64")
Removable locking connector with screw-down terminals
(2 input terminals and 2 bridge terminals)
Solid copper wire: ø0.5 – ø1.6 mm (equivalent to AWG 24 – 14)
Stranded copper wire: 0.2 – 2.5 mm
2
(equivalent to AWG 24 – 14)
Enclosure: Steel plate, plating
Baffle: Fire-resistant ABS resin (resin material grade: UL-94 V-0 or
its equivalent), black
Rim: Fire-resistant ABS resin (resin material grade: UL-94 V-0 or
its equivalent), white, paint
Punched net: Steel plate, white, paint
ø230 mm (9
1
/16") x Depth 200 mm (7
7
/8") ø230 mm (9
1
/16") x Depth 229 mm (9
1
/64")
3.7 kg (including mounting accessories)
Model No.
Enclosure
Rated Input
Power Handling Capacity
Impedance
Sound Pressure Level
Frequency Response
Speaker Component
Mounting Hole
Input Terminal
Usable Cable
Finish
Dimensions
Weight
