Owingtothespeaker’ssizeandweight,besurethatatleasttwopersons
are available to install the Speaker rigging frame.
Failuretodosocouldresultinpersonalinjury.
WARNING
4. SUSPENDING HX-7B OR HX-7W
AttachthesuspensionbracketssuppliedwitheachofHX-7BandHX-7Wspeakers,settingthedirectivityanglemodetothe
desiredmodeinadvance.WhensuspendingtwoHX-7BorHX-7Wspeakers,connecttheminadvanceusingtheHY-CN7
SeriesSpeakerconnectionbracket(optional).
Note
Refer to the instruction manual supplied with the HX-7 Series speaker for suspension bracket mounting method and
directivityanglemodemodications,andtotheHY-CN7Seriesinstallationmanualforspeakerconnections.
UptotwoHX-7BorHX-7Wspeakerscanbesuspendedtogether.Onlyverticalsuspensionispossible.
Note
WheninstallingthespeakerstogetherwithTOA’sFB-150BorFB-150WSubwoofersystem,rstperformtheoperations
explainedonthepreviouspage.
Step 1. UsingtheHX-7B’sorHX-7W’ssuspensionandrearbrackets,suspendtheHX-7BorHX-7Wat3pointsofthe
rigging frame.
Step 2. Suspendthespeaker/riggingframeassemblyfromtheceilingusingchainsorwiresandcarabinersattachedto
theriggingframein4places.
Note
TosuspendtheSpeakerriggingframeandHX-7BorHX-7Wspeaker(s),besuretousechains,wires,orcarabiners,
whichshouldbepreparedseparately.
HY-PF7B or HY-PF7W
(suspended at 4 points)
HX-7B or HX-7W
(suspended at 3 points)
Suspension bracket
(supplied with HX-7B or HX-7W)
2
1
1
1
2
2
2
Rear bracket
1
