Toa MX-106R - Connection Examples; Typical Audio Connections; System and Recording Connections

Low Z input should be connected
with low impedance (50 ohm ~ 600 ohm)
microphones
SUB MIXER (MX-106R)
Built in Power
Amplifier for
Foldback
From Speaker Jack
on Rear Panel
MAIN MIXER (MX-106R)
WIRELESS TUNER
SUCH AS WT-02,
WT-06
KEYBOARD
Line Out
Line Out
MUSICAL INSTRUMENT
From Speaker Jack
on Rear Panel
CASSETTE TAPE DECK
for recording
MAIN SPEAKER SYSTEM SPEAKER SYSTEM
for foldback
- 5 -
Connection Examples
