Todo Drive - Battery Unit; Clamps and Inners

-10 11-
Fundamental Principal of Clamps and Inners
Mount “A” part on wheelchair frame and mount “B” part on Todo Drive components.
Ø 25mm
A
Ø 25mm
B
W-Clamp (S, M, L)
T-Clamp S T-Clamp L






How to attach ‘Clamp Inner’ followed by thickness of wheelchair frame.
Clamp Inner
No Inner attached
17mm Inner
22mm Inner
25mm Inner
wheelchair frame
Ø17mm
Ø22mm
Ø25mm
Ø30mm
2.1.4 Battery Unit
No. Item Description Qt
1
B-2P Input
Circular

1
2 Battery Pack 
① B-2P Input Circular
② Battery Pack
Product Configuration and Specification
