TOHO TTM-204 Series User Manual

Output functional allotment （○：Allotment is possible、×：Allotment impossibility)
Output types
Control output Auxiliary output
Output1 Output2 Output3 Output4 Output5 Output6 Output7
Main output (Heating) ○ ○ ○ ○ ○ ○ ○
Auxiliary output (Cooling) ○ ○ ○ ○ ○ ○ ○
Transmission ○ ○ × × × × ×
Event output ○ ○ ○ ○ ○ ○ ○
Timer output ○ ○ ○ ○ ○ ○ ○
Event function 1
Function
No
Deection upper and
lower limit
Deection upper limit
Deection lower limit
Deection range
Absolute value upper
and lower limit
Absolute value upper limit
Absolute value lower limit
Absolute value range
Addition function
No
Maintenance
Standby sequence
Delay timer
Maintenance + Standby
sequence
Maintenance + Delay
timer
Standby sequence +
Delay timer
Maintenance + Standby
sequence + Delay timer
Control linkage function
All mode
RUN/MAN mode only
RUN mode only
Event function 2
(PV abnormal)
Function
No
Exsist
Addition function
No
Maintenance
Delay timer
Maintenance + Delay
timer
Control linkage function
All mode
RUN/MAN mode only
RUN mode only
Event function 3
(CT abnormal)
Function
No
CT1 abnormal
CT2 abnormal
CT1 abnormal + CT2
abnormal
Addition function
No
Maintenance
Delay timer
Maintenance + Delay
timer
Control linkage function
All mode
RUN/MAN mode only
RUN mode only
Event function 4
(Loop wire break)
Function
No
Exsist
Addition function
No
Exsist
* Event polarity function
available
■Point of contact output mode■Timer drive mode
Start mode
1 Auto start
2 Manual start
3 SV start
4 DI1 start (Possible to set when option is equipped)
5 DI2 start (Possible to set when option is equipped)
6 DI3 start (Possible to set when option is equipped)
7 DI4 start (Possible to set when option is equipped)
8 Event 1 start
9 Event 2 start
10 Event 3 start (Possible to set when option is equipped)
11 Event 4 start (Possible to set when option is equipped)
12 Event 5 start (Possible to set when option is equipped)
13 Event 6 start (Possible to set when option is equipped)
14 Event 7 start (Possible to set when option is equipped)
＊Each Start has ON delay/OFF Delay
ON delay: After time-up control stop or event output OFF
OFF delay: After time-up control stop or event output ON
