TOHO TTM-204 Series User Manual

■Input and scale range
Thermocouple Measurement/measurement range Indication resolution
K ℃ －200.0 to 1372.0 1℃／0.1℃
J ℃ －200.0 to 1200.0 1℃／0.1℃
T ℃ －200.0 to 400.0 1℃／0.1℃
E ℃ －200.0 to 1000.0 1℃／0.1℃
R ℃ －50.0 to 1768.0 1℃
S ℃ －50.0 to 1768.0 1℃
B ℃ －0.0 to 1800.0 1℃
N ℃ －200.0 to 1300.0 1℃／0.1℃
U ℃ －200.0 to 400.0 1℃／0.1℃
L ℃ －200.0 to 900.0 1℃／0.1℃
WRe5－26 ℃ 0.0 to 2300.0 1℃
PR40－20 ℃ 0.0 to 1880.0 1℃
PLⅡ ℃ 0.0 to 1390.0 1℃／0.1℃
RTD Measurement/measurement range Indication resolution
Pt100（JIS/IEC） ℃ －200.0 to 850.0 1℃／0.1℃
JPt100（JIS） ℃ －200.0 to 510.0 1℃／0.1℃
Current and voltage Measurement/measurement range Indication resolution
0 to 1VDC
－19999 to 29999
Indication width is less than
20000.
A decimal point position can
be changed arbitrarily.
0 to 5VDC
1 to 5VDC
0 to 10VDC
0 to 10mVDC
4 to 20mADC
■Output connection setting
Main output
Auxiliary output
Event output
RUN output
RDY output
Timer1 output
Timer1 output at on delay
Timer1 output at o󱐯 delay
Timer1 output at on + o󱐯 delay
Timer2 output
Timer2 output at on delay
Timer2 output at o󱐯 delay
Timer2 output at on + o󱐯 delay
Timer3 output
Timer3 output at on delay
Timer3 output at o󱐯 delay
Timer3 output at on + o󱐯 delay
Transmission output (When OUT1 and OUT2 are analogue output)
■Option Specications (Continued)
Remote SV Input Input Type (Current/Voltage Multi-Input) 0 to 1VDC, 0 to 5VDC, 1〜5VDC, 0 to 10VDC, 4 to 20mADC
Measurement/Range of Setting －19999 to＋29999 (decimal point can be set at any location)
Range of Display (Full Scale: Range
of FSL2 to FSH2)
0 to 1VDC, 0 to 5VDC,
0 to 10VDC
High Limit: ＋12% of full scale
Low Limit: Maximum of －2% of full scale
1 to 5VDC, 4 to 20mADC High Limit: ＋12% of full scale
Low Limit: －12% of full scale
Resolution ±0.3% of full scale＋1 digit
Display scaling High Limit (FSH2): FSL2 to 29999 (digit)
High limit (FSH2)/Low limit (FSL2) Low Limit (FSL2): －19999 to FSH2 (digit)
Display Resolution Performance 20000 or less
PV Correction Zero-Point Setting (PVS2) －9999 to 9999 (digit)
PV Correction Gain Setting (PVG2) 0.500 to 2.000 (Multiple)
PV Input Filter (PDF2) 0.0 to 99.9 (seconds)
Local/Remote Switch Local, remote 1 (scaling with SLL1 and SLH1)
Remote 2 (scaling with FSL2 and FSH2)
