Optional accessories
1) Jig connection cable FC64-1.2K
2) Printer WKE-07
3) Tape cutter WTC-100E
4) "OK" marker OM-01
64 wires flat cable with connector at one side.
Cable length : 1.2 meters cable
(Possible to arrange an optional length on request)
Function :
Print out of connection data, test
results, etc.
Features : High speed printing, light weight
Interface : RS-232C Serial interface
Accessories : connection cable, AC adaptor
Size & weight : 106(W) x 106(H) x 180(D) mm
0.5 Kgs.
When the test object (wire harness) is passed
the test, a fixed length of tape will come out and
paste a "OK" mark to the object.
(The tape length : 1 ~ 12 cm adjustable)
With a buzzer for tape cutting error.
Tape role : Cellophane tape (
1 or 3" inner dia.)
Size & weight : 91(W) x 128(H) x 178(D) mm
1.3 Kgs.
When the test object (wire harness) is passed
the test, a "OK" mark will be put automatically.
Available to change the mark.
Possible to combine the fitting position and the
mark position optionally.
Size : 74(W) x 50(H) x 28(D) mm
Nov. 7, 2006
Test name : A-150-0042
#1001 OK
50
28
74
64C
39-6, Udagawa-cho, Shibuya-ku, Tokyo 150-0042, Japan Tel : 81-3-3463-2161 Fax : 81-3-3496-9550
