Tokyo Keiki UFP-20 User Manual

3-4
3.2.2 Main Unit specifications
Power
Supply
DC 10
~ 30 V
Battery DC 6.0 V 4.0 Ah Ni-MH
Standard operation time : 8hours
(When analog output and USB memory are not connected.)
Rapid charging time : 4hours
Note) The range of the temperature of the battery that can be
charged is Approx. 0 ~ 50 °C. It is not possible to charge it
outside this range.
AC adaptor Output : DC 12 V 5 A
Input : AC 90 ~ 264 V 47 - 63 Hz 1.5 A(AC 90 V)
Power
Consumption
Approx. 5 W
Approx. 20 W
Approx. 5 W
Approx. 20 W
(DC 24 V supply, Main unit operates)
(DC 24 V supply, Battery is charged)
(DC 12 V supply, Main unit operates)
(DC 12 V supply, Battery is charged)
Note) When the power supply of main unit is turned off with the AC adaptor connected,
the battery is charged.
Operating
Temperature
-10 ~ 50 °C
(for AC adaptor : 0 ~ 40 °C)
Storage
Temperature
-10 ~ 50 °C
(for AC adaptor : -20 ~ 85 °C)
Operating
Humidity
20 ~ 90 %RH (non-condensation)
Protection
Degree
IP65 (IEC 60529)
Note) It is non-waterproof while connected with the AC adaptor or USB memory.
Material
Polycarbonate/ABS
Dimension
135（W）x 250（L）x 68（H）
Mass Approx. 1.4kg (including battery)
European
Compliance
(CE marking)
EMC Directive 2014/30/EU
Harmonized Standard / EN61326-1:2013
-Separation into group / Group I
-Division into classes / Class A
-Location intended for use / In industrial locations
RoHS Directive 2011/65/EU
Harmonized Standard / EN 50581:2012
[Condition]
AC Adaptor is only used to recharge the battery.
The length of sensor cable is 7m.

Tokyo Keiki UFP-20 Specifications

General

Type	Ultrasonic Flow Meter
Fluid Type	Liquids
Accuracy	±1% of reading
Output	4-20 mA, Pulse
Power Supply	24 VDC or 100-240 VAC
Output Signal	4-20 mA, Pulse
Operating Temperature	-20 to 60°C
