975L-5310 Wiring
RED +12Vdc
BLACK Ground
ORANGE Warning Mode 1, with optional CA Steady behavior
BLUE Warning Mode 2, with optional CA Steady behavior
ORANGE & BLUE Warning Mode 3, with optional CA Steady behavior
RED/WHITE Right Arrow Mode
BROWN/WHITE Left Arrow Mode
RED/WHITE & BROWN/WHITE Center Out Arrow Mode
BROWN Scene Lights (if equipped)
GREEN Intensity Control
Programming Instructions
Entering Warning Programming Mode:
Three unique warning patterns can be selected using the ORANGE and BLUE mode selection wires.
ORANGE WIRE = Warning Mode 1
BLUE WIRE = Warning Mode 2
ORANGE & BLUE WIRES = Warning Mode 3
To activate the Warning programming mode, connect the BLACK wire to Ground then simultaneously attach the
GREEN wire, the RED wire and the mode selection wire(s) for the mode you want to program to +12Vdc.
Changing Warning Patterns and Flash Rates:
To change the Warning pattern, enter the Warning programming mode as described above, including selecting a
mode. Tap the RED/WHITE wire to +12Vdc to advance the flash pattern. See the list of available Warning flash
patterns below.
A unique flash rate can be assigned to each Warning mode. To change the flash rate, enter the Warning programming
mode as described above, including selecting a mode. Move the GREEN wire from +12Vdc to Ground. Tap the
BROWN/WHITE wire to +12Vdc to advance the flash rate. See the list of available flash rates below.
Changing CA Steady Behavior for Warning Modes:
To change the CA Steady behavior for a Warning Mode, enter the Warning programming mode as described above.
Tap the BROWN wire to +12Vdc to Toggle the CA Steady behavior On (or Off). NOTE: The position of the lamp for
the CA Steady behavior is fixed, and cannot be changed via Programming.
