Entering Traffic Direction Programming Mode:
To activate the Traffic Direction programming mode connect the BLACK wire to Ground then simultaneously attach the
GREEN wire, RED/WHITE wire and the RED wire to +12Vdc.
Changing Traffic Direction Patterns and Flash Rates:
To change the Traffic Direction pattern, enter the Traffic Direction programming mode as described above. Tap the
BROWN wire to +12Vdc to advance the flash pattern. See the list of available Traffic Direction patterns below.
A unique flash rate can be assigned to the Traffic Direction mode. To change the flash rate, enter the Traffic Direction
programming mode as described above. Move the GREEN wire from +12Vdc to Ground. Tap the BROWN wire to
+12Vdc to advance the flash rate. See the list of available flash rates below.
Flash Rates, Warning Modes:
1) SINGLE FLASH 312 FPM
2) DOUBLE FLASH 117 FPM **
3) NEOBE FLASH 77 FPM **
4) SINGLE 75 FLASH 75 FPM **
5) SCROLL FLASH A switches between the Single, Double and Neobe flash rates, every 4 seconds
6) SCROLL FLASH B ** switches between the Single 75, Double and Neobe flash rates, every 4 seconds.
Flash Patterns, Warning Modes - Models 5310-01, 5310-C01
1) OFF
2) COMBINATION A
(Patterns 6,5,7,5 repeat) ORANGE Wire (Warning Mode 1) DEFAULT, SCROLL FLASH A
3) COMBINATION B
(Patterns 6,5,4,5 repeat) **
4) INBOARD OUTBOARD
** BLUE Wire (Warning Mode 2) DEFAULT, SCROLL FLASH A
5) LEFT RIGHT
** ORANGE & BLUE Wires (Warning Mode 3) DEFAULT, SCROLL FLASH A
6) ALTERNATE
**
7) RANDOM
8) SINGLE OUTBOARD
**
9) DOUBLE OUTBOARD
**
10) SINGLE INBOARD
**
11) DOUBLE INBOARD
**
12) TRIPLE INBOARD
**
13) SWEEP
** = CA Title 13 compliant
NOTE: If the CA Steady behavior is ON for a Warning Mode, a lamp will turn on steady when the Warning Mode is
activated.
