HANDY PACHYMETER SP-100
Doc. No
(3) Cannot measure with human eye and model eye.
Cause1: Machine does not go measurement mode.
[Countermeasure]>>Select measurement mode, and then start measurement.
Cause2: Broken Pachy probe.
[Countermeasure]>> Check the condition of Pachy probe.
If problem still remain, replace Pachy probe.
Cause3: Incorrect connections of Pachy probe.
[Countermeasure]>> Check the connection of Pachy probe.
Cause4: Probe angle.
[Countermeasure]>> When you measure human eye or model eye, you have to keep vertical
against for eyeball or test piece.
Cause6: Defective Main board.
[Countermeasure]>>Check the Main board (792-010A) and if there is a problem, replace Main board.
(4) Measurement data is not printed out.
Cause1: Paper jamming.
[Countermeasure]>> Check the condition of paper. If it is jamming, remove jamming paper from outlet side
and set paper in correct position.
Cause2: Defective Membrane switch.
[Countermeasure]>>Check the Membrane switch (792-021A). If it is broken, replace Membrane switch.
Cause3: Defective Printer.
[Countermeasure]>>Check the Thermal printer (E20-0026). If it is broken, replace Thermal printer.
