1
We recommend you level your shoreline with Blocks. Level shoreline Blocks will stabilize your dock and ensure a good start.
While onshore, install Brackets on section (refer to dock layout and bracket installation sheets for correct bracket location
and installation). We recommend the use of sawhorses or other suitable level work area for hardware installation. When
installing Brackets for a tee section, measure the correct distance of mating docks (standard width is 47-3/4”).
2
Install predetermined length of Post through Brackets (2a) and temporarily tighten Bracket Adjusting Bolts (2b) leaving
3” of post below the bottom of each Bracket (2c).
4
www.tommydocks.com
3”
2a
2c
2b
Bracket
Adjusting Bolt
3/4”
3”
Bracket
Post
To Next Page
