Mechanical
Size 87.8 x 43.0 x 15.1 mm
Weight 68g
Power
Battery 1200mAh Lithium Ion built-in cell
Battery life 10hours typical use
Charge time Less than 4 hours
Voltage 4.75V to 6V
Charging
From CLA (cigarette lighter adaptor) or AC
Adaptor
GPS
Chipset SiRF Star III
Frequency L1, 1575.42MHz
C/A Code 1.023 MHz Chip Rate
Channels 20 channel all-in-view tracking
Tracking sensitivity -159dBm
Update rate 1Hz
Cold start <1 minute typical
Warm start <30 seconds typical
Hot start <10 seconds typical
Reacquisition time <1 second from max 30second blockage
Datum WGS-84
Protocol NMEA 0183 Version 2.2
Antenna Built-in omnidirectional antenna
Bluetooth
Prole Serial Port Prole (SPP)
Class Class II Version 1.2
Default PIN 0000
Environmental
Storage Temperature -20 to +70 degrees Celsius
Operating Temperature -10 to +60 degrees Celsius
Humidity Up to 75% non-condensing
Fluid & Dust Protection IP54
Technical Specications
