4. Press down the polisher’s self-lock, and use the Angle Wrench to twist
the input shaft clockwise. Until it is loose from the spindle of the polisher.
5. Remove polisher from planetary base.
6. Clean the assembly and lubricate the input shaft threads. Store the
planetary base in a dry place.
Press down the
self-lock.
R
otate the Wrench
clockwise to loosen.
