1. Fix 2 x Guide Rods (8) to the right Base Frame (2) using 2 x M10×25mm Allen Bolts (43).
2. Put the Guide Rod (8) through 1 x Rubber Bumper (28), 1 x Shock Spring (27) and 1 x Rubber
Bumper (28) sequentially.
3. Put the Guide Rod (8) through 15× 5kg Selector Stems (29).
4. Respectively put 2 x Weight Stem Guiding Sleeve (31) into the 4kg Selector Stem (30), insert the
Selector Rod (22) into the 4kg Selector Stem (30), screw 2 x M10×25mm Allen Bolts (36) in the 4kg
Selector Stem (30) and fix the Selector Rod (22).
5. Put the Guide Rod (8) through 1 x 4kg Selector Stem (30).
6. Stick the weight sticker (32) as shown in the diagram, from top to bottom sticking 5kg, 10kg, 15kg,
20kg, 25kg, 30kg, 35kg, 40kg, 45kg, 50kg，55kg，60kg，65kg，70kg，75kg，80kg.
