Step 4
1. Attach 2 x Upper Frames (6) and 2 x Flat Brackets (21) to 2 x Middle Vertical Support (4) and Guide
Tube (5) respectively using 4 x M10×60mm Carriage Bolts (37), 4 x φ10mm Washers (48) and 4 x M10
Aircraft Nuts (49).
2. Connect 1 x Cross Beam (3) to 2 x Rear Vertical Support (1) and 2 x Upper Frame (6) using 4 x
M10×60mm Carriage Bolts (37), 4 x φ10mm Washers (48) and 4 x M10 Aircraft Nuts (49).
