TOORX ERX3000 - Part List

Part List:
Part NO. Description Material Specification QTY
1 Main frame 1
2 Front stabilizer 1
3 Flat washer Q235A D16xD8.5x1.2T 16
4L Rear left foot cap PE 95.7*57.2*51.3 2
4R Rear right foot cap PE 95.7*57.2*51.3 2
5 Wheel PP D65*24 2
6 Curved washer Q235A D22xD8.5x1.5T 4
7 Spring washer 70# D15.4xD8.2x2T 22
8 Round end cap PE D50x15L 2
9 Allen bolt 35# M8x1.25x20L,8.8 16
10 Handlebar post 1
11 Pedal supporting tube 2
12L Left movable supporting tube 1
12R Right movable supporting tube 1
13 Bearing GCr15 #2203-2RS 2
14 C ring 65Mn S-40(1.8T) D40 2
15 End cap PE6070 D25.4*31L 2
16 Idle wheel NL+FIBER D44*21L,6002ZZ 1
17 Allen bolt 35# M8*1.25*50L,8.8 4
19 Rear stabilizer Q195 95.4*50.6*2.0Tx500L 1
20 Square bolt Q235A M6*1*45L 4
21L Left pedal PP 407*133.5*77.5 1
21R Right pedal PP 407*133.5*77.5 1
22 Cross screw 10# ST4*1.41*15L 8
23 Protective cover ABS 100*81*40.8 1
24 Anti-loose nut 35# M10*1.25*10T 2
25 Pin ABS D6*26.5*7.7 3
26 C ring 65Mn D22.5*D18.5*1.2T 2
27 Adaptor
Out：26V,2.3A
1
28 Connect cable 500L 1
29 Upper computer cable 1000L 1
30 Lower computer cable 1500L 1
31 Pedal axle cover PP D46*39L 2
32 Round end cap PE D45*15 2
33L Left crank welding sets 1
33R Right crank welding sets 1
