TOORX MSX50 - Step 5: Front Press & Pulley Installation

Attach the Front Press Frame(15#) to the Upper Frame(12#), Secure them with 1pcs axle(26#),2pcs φ
25×φ10.5×б1.5 washer（45#）and 2pcs M10 Aircraft nut (46#).
Attach the swivel pulley bracket(19#) to the support as the diagram shows, and secure it with 1pc
M10X65Allen Bolt (31#) ,2X φ10 washer (44#) and 1pc M10 Aircraft nut (46#). Repeat the same way to
install another.
note：
20X40X1.5 End cap （61#）was fixed in the factory already。
Step 5
Assembly instructions
11
