Attach the 2pcs handle(4#) to the right and left butterfly frame as the diagram shows. Secure them with
2pcs M10*25 Allen bolt(37#) and 2pcs Ø10 washer (44#).
Insert the leg press frame(10#) into the hole as the diagram shows and select the desired height with
the lock knob(84#).
Insert the leg press adjustment (105#) into the leg press frame(10#) and select the desired length with
the lock knob(83#).
note：□50X□45 Sleeve (66#）,□45X1.5 End cap （58#）were fixed in the factory already.
