23
❏
7. Position the radiators on the bottom of the wing,
behind the retract and perpendicular to the root of the
wing. Mark the location on the covering and use a T-pin
to poke holes in the covering, inside the marks. Glue
the radiators to the bottom of the wing with epoxy.
❏
8. Glue the plywood rudder spacer to the back of
the plastic rudder pedal. Trim the rudder pedal so that
it is fl ush with the rudder spacer. A sanding bar can
be used to sand the edges of the plastic rudder pedal
fl ush with the spacer. For additional detail, the recessed
area around the rudder pedals can be painted fl at black.
❏
9. Apply the instrument panel decal to the plywood
instrument panel backplate. Glue the backplate behind
the instrument panel, positioning the backplate so that
the instrument dials line-up with the openings.
