1. DESCRIPTION
(see front cover)
2. INSTALLATION
2.1. Removing/Installing the Belt Clip
1. To remove the clip from the unit, push up on the belt clip (2) while pulling
the clip tab (1).
2. When re-installing the belt clip, a click indicates the BeltClip is locked into
position.
2.2. Battery Installation
1. Remove the belt clip (2).
2. Pull the Battery Cover Tab (4) and remove the Battery Cover (3).
3. Install four ‘AAA’ alkaline or rechargeable batteries following the polarity as
shown.
4. Re-install the Battery Cover (3) and Belt Clip (2).
1. Microphone
2. Monitor button
3. Talk button
4. Call button
5. Transmission LED
6. Ear/mic/charger
7. Antenna
8. LCD display
9. Up/Down button
10.Menu/Lock button
11. On/Off button
12.Scan button
13.Speaker
4
3
1
2
