2 in 1 full features cradle (desktop dock station or vehicle
cradle)
1. To be desktop dock station
- Metal plate at the bottom
- Mainly use the connector (type C for charging) at the back. Please note that the adapter needs to be
high power (Support PD fast charging)
2. To be vehicle cradle
- No metal plate at the bottom
- Use the molex connector at the bottom. The LAN (RJ45) connector and other connector at the back is
optional. If not used, it can be closed by a plastic tape, see below
Without metal plate
Lock the Molex connector to the cradle by screw
