Note: If the “11” is be set, the gate opener won’t work until the PBS system is equipped. The PBS
system works only when gate opener is closing. The gate opener will return to its open position when
the obstruction blocks the beam from photo eye.
indicates “11”, the PBS is available. The Digital Display indicates “00”, the PBS is null.
Press the “FUNC” button to store the data when the PBS is set. The Digital Display will indicate “PA”.
(Factory set is “00”)
9. Set the Automatic Closing Time
When the Digital Display indicates “PA”, the gate opener enters into the setting of automatic closing time mode.
Press and release the “INC” or “DEC” button, the Digital Display will show a “01”-“99” which indicates the current
automatic closing time. The minimum time is 1 second, 99 seconds maximum. Each time you press and release
the “INC” button, the figure increases by 1, and the timing increases by 1 second. Each time you press and release
the “DEC” button, the figure decreases by 1, and the timing decreases by 1 second. When the timing is “00”, the
automatic closing function is shut off and the gate will stay open.
(Factory set is 60 seconds)
Press the “FUNC” button to store the data when the desired automatic closing time is set. The Digital Display will
indicate “Pb”
10. Set the Period of Soft Start
When the Digital Display indicates “Pb”, the gate opener is ready for setting period of soft start.
You can press the “INC” or “DEC” button to set the period of soft start. There is 1-9 seconds available in setting.
Press the “FUNC” button to store the data when the period is set. The Digital Display will indicate “PC”.
(Factory set is 3 seconds)
11. Set the Fast Running Period (FRP) to Achieve Soft Stop Function (SPP)
When the Digital Display indicates “PC”, the Fast Running Period for opening or closing gate is adjustable by
pressing “INC” and “DEC” buttons respectively, and the Soft Stop Function is achieved simultaneously.
The Soft Stop means the gate opener runs at slow speed during the last period before the gate completely closes.
The Soft Stop Period is unavailable by direct adjust but available through adjusting the Fast Running Period.
There are two running speeds designed in program, i.e. Fast Running Speed and Soft Running Speed. The Fast
Running Period is adjustable from 1 to 28 sec. Factory default setting is 15 sec.
Since the GATE OPENING OR CLOSING RUNING PERIOD (GRP) = SOFT START PERIOD (STP) + FAST
RUNNING PERIOD (FRP) + SOFT STOP PERIOD (SPP), the SPP could be extended by shortening the FRP
when the GRP and STP are fixed. In other words, SPP = GRP–STP–FRP.
Similarly, the Soft Stop Period (SPP) can be shortened through extending the Fast Running Period (FPP).
E.g. When the Soft Start Period (STP) is set at 3 sec, and the GRP is 23 sec, how can we get 4 sec of Soft Stop
Period (SPP) to meet the requirement? The answer is clear, i.e. we may set the Fast Running Period (FRP) at 16
sec (23 – 3 – 4 =16 sec).
12. Return to Factory Set
When the Digital Display indicates “Pd”, press and release the “INC” or “DEC” button. All data will return to factory
set, the Digital Display indicates “dF”.
13. If all of data is set and no other change needed, press “FUNC” Button. “- -” appears on the Digital Display, and
the opener enters standby mode.
Indicate Illustration on the Digital Display When Gate Opener is Running
The left image on Digital Display symbolizes motor of gate opener 2 when the gate opener is running. The right
image on Digital Display symbolizes motor of gate opener 1.
When the motor is run to gate -open direction or gate -close direction, the image on Digital Display indicates “n”
or “u” respectively.
When the motor is not running, the Digital Display indicates “- -”.
