5
CONTENU DU KIT
KIT CONTENT
PIECES MOTEUR
(A) Cône Ø52mm ...................................................................................................1
(B) Bâti-moteur avec visserie ..........................................................................1 set
(C) Réservoir 280cc ........................................................................................1 set
(D) Tringlerie gaz ............................................................................................1 set
DIVERS
(A) Buste pilote .....................................................................................................1
(B) Bâti de montage pour moteur électrique ..................................................1 set
(C) Manuel de montage .........................................................................................1
ENGINE PARTS
(A) 2’ spinner ........................................................................................................1
(B) Engine mount with screws.........................................................................1 set
(C) 280cc tank .................................................................................................1 set
(D) Throttle linkage .........................................................................................1 set
VARIOUS
(A) Pilot bust .........................................................................................................1
(B) Motor engine mount ..................................................................................1 set
(C) Construction manual ........................................................................................1
WINGS PARTS
(A) Wing (with aileron installed on their hinge to be glued) (L/R) ............... 1 each
(B) Plywood wing joiner .........................................................................................1
(C) Aileron linkage .................................................................................................2
(D) M2 metal clevis ...............................................................................................2
(E) Ailerons control horn ............................................................................... 2 sets
(F) Formed main gear leg .....................................................................................2
(G) Main gear leg fixing (nylon strap + welf-tapping screw) .......................... 4+8
(H) Diameter 68mm wheel ....................................................................................2
(I) Wheel stopper ........................................................................................... 3 sets
(J) Wing plastic bolt ...............................................................................................2
FUSELAGE-TAIL PARTS
(A) Fuselage (with canopy and upper cowl installed) .....................................1 set
(B) Elevator linkage (music wire) ..........................................................................2
(C) Rudder linkage (music wire) ............................................................................1
(D) Steering wheel linkage (music wire) ...............................................................1
(E) M2 metal clevis ................................................................................................3
(F) Adjustable rod stopper ............................................................................ 2 sets
(G) Triple rod connector ........................................................................................1
(H) Control horn ............................................................................................ 2 sets
(I) Front gear ...................................................................................................1 set
(J) Wheel ................................................................................................................1
(K) Horizontal tail ............................................................................................1 set
(L) Vertical tail .................................................................................................1 set
PIECES AILES
(A) Aile (avec aileron sur charnières et à coller) (G/D) ......................1 de chaque
(B) Clé d’aile CTP...................................................................................................1
(C) Tringlerie ailerons ............................................................................................2
(D) Chape métal M2 ..............................................................................................2
(E) Guignol aileron ........................................................................................2 sets
(F) Jambe de train principal CAP ...........................................................................2
(G) Fixation train principal (cavalier plastique + vis à bois)........................... 4+8
(H) Roue Ø68mm ..................................................................................................2
(I) Bague arrêt de roue................................................................................. 3 sets
(J) Vis plastique fixation d’aile ...............................................................................2
PIECES FUSELAGE-EMPENNAGES
(A) Fuselage (avec verrière et capot supérieur installés) ..............................1 set
(B) Tringlerie profondeur (CAP) ............................................................................2
(C) Tringlerie direction (CAP) ................................................................................1
(D) Tringlerie dirigibilité (CAP) ..............................................................................1
(E) Chape métal M2 ..............................................................................................3
(F) Domino .................................................................................................... 2 sets
(G) Connecteur triple .............................................................................................1
(H) Guignol .................................................................................................... 2 sets
(I) Train avant ..................................................................................................1 set
(J) Roue .................................................................................................................1
(K) Empennage horizontal ..............................................................................1 set
(L) Empennage vertical ...................................................................................1 set
MARACANA
MARACANA
