5.4- ELECTRIC CONNECTIONS (Wiring diagram)
THE ELECTRIC CONNECTION OF THE VERSION ACK44 HAS TO BE CARRIED OUT WITH
A VERY LOW SAFETY VOLTAGE FEEDER PROTECTED AGAINST SHORT CIRCUITS.
W.
THE MAINS TO WHICH THE ACTUATOR IS CONNECTED MUST COMPLY WITH THE
REQUIREMENTS OF THE LAWS IN FORCE IN THE COUNTRY OF INSTALLATION, AS
WELL AS SATISFY THE TECHNICAL FEATURES GIVEN IN TAB. 1 AND ON THE RATING
PLATE AND THE "CE" MARKING (PAR. 3.1).
THE SECTION OF THE MAINS CABLES MUST BE PROPERLY SIZED ACCORDING TO THE
ABSORBED ELECTRIC POWER (SEE RATING PLATE AND "CE" MARKING).
ANY TYPE OF ELECTRIC MATERIAL (PLUG, CABLE, TERMINALS, ETC.) USED FOR THE
CONNECTION MUST BE SUITABLE FOR THE USE, WITH "CE" MARKING AND
COMPLYING WITH THE REQUIREMENTS FORESEEN BY THE LAWS IN FORCE IN THE
COUNTRY OF INSTALLATION.
BEFORE PERFORMING THE ELECTRIC CONNECTION OF THE ACTUATOR, VERIFY
THAT THE POWER SUPPLY CABLE IS NOT DAMAGED. SHOULD IT BE DAMAGED, IT
MUST BE REPLACED BY THE MANUFACTURER OR BY THE TECHNICAL ASSISTANCE
SERVICE OR IN ANY CASE BY AUTHORIZED OPERATORS.
5.5- CONTROL DEVICES
THE CONTROL DEVICES USED TO DRIVE THE ACTUATOR MUST ASSURE THE SAFETY
CONDITIONS FORESEEN BY THE LAWS IN FORCE IN THE COUNTRY OF USE.
According to the different type of installations, the actuators can be driven by the
following control devices:
1) MANUAL PUSH-BUTTON:
Bipolar switch button with central OFF position, with biased-off switch;
THE ELECTRIC CONNECTION OF THE ACTUATOR CAN BE PERFORMED ONLY BY
COMPETENT AND QUALIFIED TECHNICAL PERSONNEL SATISFYING THE TECHNICAL
AND PROFESSIONAL REQUIREMENTS FORESEEN BY THE LAW IN FORCE IN THE
COUNTRY OF INSTALLATION ISSUING TO THE CUSTOMER A DECLARATION OF
CONFORMITY FOR THE CONNECTION AND/OR THE PLANT PERFORMED.
BEFORE PERFORMING THE ELECTRIC CONNECTION OF THE ACTUATOR, VERIFY THE
CORRECT INSTALLATION ON THE WINDO
TO ASSURE EFFICIENT SEPARATION FROM THE MAINS, INSTALL AN APPROVED
TEMPORARY BIPOLAR SWITCH (PUSH-BUTTON) UPLINE OF THE DEVICE. FIT A
BIPOLAR MAIN SWITCH WITH CONTACT APERTURE OF AT LEAST 3 mm UP LONE OF
THE CONTROL LINE.
19
ACK4
INSTALLATION -5
INSTALLATION AND USE ISTRUCTIONS
VER.0.0
REV.11.12
